Tawm tsam nrog cov kab sib chaws tsis ruaj khov lossis kev ua haujlwm nyob deb? 3 units ntawm peb 600KW Cummins generator xa 43,200 kWh txhua hnub nrog ZERO unplanned downtime ntawm Indonesia tus npib tsib xee mine - daws lawv cov siab - cua sov, siab - av humidity power crisis.
3 Core Advantages at a Glance
|
Roj Efficiency & Voltage Stability |
Txhua yam -Climate Adaptability |
Qhov System-Level Reliability |
|
Kev siv roj tsawg dua lossis sib npaug li 205g / kWh |
-40℃~ 50℃kev khiav hauj lwm ntau yam |
99.5% pom efficiency |
|
Voltage fluctuation<1% |
IP55 tiv thaiv plua plav / dej |
10, 000+ teev tsim lub neej |
daws koj cov teeb meem tseem ceeb zog
1. Roj Efficiency & Voltage Stability
Kev txhawj xeeb txog cov nqi hluav taws xob siab lossis cov khoom siv hluav taws xob puas tsuaj? Peb lub cav Cummins muab 15% zoo dua roj efficiency dua li cov qauv generators, thaum cov kev cai siab tshaj voltage ua kom muaj kev hloov pauv hauv qab 1%- tiv thaiv CNC tshuab, cov cuab yeej kho mob, thiab cov khoom siv hluav taws xob tsis zoo los ntawm lub zog tsis ruaj khov.
2. Txhua yam -Climate Adaptability
Thaum tshav kub kub, txias, lossis plua plav puas ua rau koj cov haujlwm? Chav tsev no vam meej hauv -40℃polar txias rau 50℃equatorial tshav kub, nrog IP55 tiv thaiv thaiv plua plav thiab ya raws. Zoo meej rau qhov chaw mining, kev tsim kho tej thaj chaw deb, lossis chaw ntug hiav txwv.
3. Qhov System-Level Reliability
Ntxim qab ua luaj? Los ntawm kev nkag mus rau qhov tso pa tawm, txhua qhov system tau ua kom zoo rau lub neej ntev:
Ob npaug - theem cua lim (99.5% efficiency) tiv thaiv lub cav hnav
Copper-cov tub ntxhais txias qhov system tsis txhob overheating
HGM6110/6120 tswj vaj huam sib luag ua rau tsis siv neeg tiv thaiv kev ua txhaum
Kev Kho Kom Zoo Rau Koj Qhov Scene
|
Kev teeb tsa |
Zoo tshaj rau |
Cov txiaj ntsig tseem ceeb |
|
Qhib Ncej |
Mines, qhov chaw tsim kho |
Kev saib xyuas yooj yim + rugged tsim |
|
Silent Enclosure |
Tsev kho mob, cov chaw zov me nyuam |
Tsawg dua los yog sib npaug rau 75dB suab nrov ua haujlwm |
|
Txawb Trailer |
Tej yaam num nyob deb |
Npaj siv hauv 1 teev |
|
Rainproof Canopy |
Sab nraum zoov warehouses, ua liaj ua teb |
Tag nrho - huab cua tiv thaiv |
Customization Options
Voltage / zaus hloov kho
Alternator hom (Keneng, Stanford, Leroy-Somer)
SCR / DPF emission txo cov tshuab
Case tiag: Indonesia Nickel Mine
Kev Sib Tw: Cov phiaj xwm tsis ruaj khov hauv zos + 35℃+ av noo cuam tshuam kev ua haujlwm tsuas.
Kev daws: 3 x 600KW Cummins generators (kev cai siab -temp cooling + modular design).
Cov txiaj ntsig: 24/7 kev ua haujlwm, 43,200 kWh cov zis txhua hnub, ZERO downtime- cov neeg siv khoom ntaus lub hom phiaj 2 lub lis piam ntxov.
Khoom Parameters ntawm 600KW Cummins Generator Teeb
|
Generator Qauv |
Diesel Generator |
Diesel Cav |
Alternator |
Loj |
Qhov hnyav |
|||
|
Prime hwj chim (KW / KVA) |
Standby fais fab mov (KW / KVA) |
Qauv |
Hwj chim |
Qauv |
Hwj chim |
|||
|
KNC 20 GF |
20/25 |
22/27 |
4B3.9-G11 |
20/23 |
KN-20 |
22/25 |
1600x700x1100 |
700 |
|
KNC 24 GF |
24/30 |
26/32 |
4BT3.9-G2 |
24/30 |
KN-24 |
24/30 |
1600x700x1100 |
750 |
|
KNC 30 GF |
30/37 |
33/41 |
4BT3.9-G1 |
36 |
KN-30 |
30/37 |
1600x700x1100 |
800 |
|
KNC 40 GF |
40/50 |
44/55 |
4BTA3.9-G2 |
50/60 |
KN-40 |
40/50 |
1700x700x1300 |
850 |
|
KNC 50 GF |
50/62 |
55/68 |
4BTA3.9-G2 |
58/67 |
KN-50 |
50/62 |
1800x750x1300 |
900 |
|
KNC 60 GF |
60/75 |
66/82 |
4BTA3.9-G11 |
70/80 |
KN-60 |
60/75 |
2300x800x1500 |
1000 |
|
KNC 75 GF |
75/93 |
82/103 |
4BTA3.9-G13 |
87/97 |
KN-75 |
75/93 |
2300x800x1500 |
1000 |
|
KNC 80 GF |
80/100 |
88/110 |
6BT5.9-G2 |
86/100 |
KN-80 |
80/100 |
2300x800x1500 |
1000 |
|
KNC 100 GF |
100/125 |
110/156 |
6BTAA5.9-G2 |
120/132 |
KN-100 |
100/125 |
2500x800x1500 |
1200 |
|
KNC 120 GF |
120/150 |
132/165 |
6BTAA5.9-G12 |
140/150 |
KN-120 |
120/150 |
2500x800x1500 |
1300 |
|
KNC 150 GF |
150/187 |
165/206 |
6 CTA8.3-G1 |
163 |
KN-150 |
150/187 |
2600x950x1600 |
1800 |
|
KNC 200 GF |
200/250 |
220/275 |
6 CTAA8.3-G9 |
231/263 |
KN-200 |
200/250 |
3000x1000x1600 |
3000 |
|
KNC 250 GF |
250/312 |
275/343 |
6 LTAA9.5-G1 |
280/290 |
KN-250 |
250/312 |
3300x1100x1800 |
3200 |
|
KNC 300 GF |
300/375 |
330/412 |
6 ZTAA13-G3 |
340 |
KN-3300 Nws |
300/375 |
3300x1100x1800 |
3500 |
|
KNC 350 GF |
350/437 |
385/481 |
6 ZTAA13-G2 |
390 |
KN-350 |
350/437 |
3300x1100x1800 |
3500 |
|
KNC 400 GF |
400/500 |
440/550 |
6 ZTAA13-G4 |
400 |
KN-400 Nws |
400/500 |
3500x1400x2000 |
4000 |
|
KNC 450 GF |
450/562 |
495/618 |
QSZ13-G10 |
463 |
KN-450 |
450/562 |
3500x1400x2000 |
4000 |
|
KNC 500 GF |
500/625 |
550/687 |
KTAA19-G6A |
610 |
KN-500 Nws |
500/625 |
3700x1800x2000 |
4200 |
|
KNC 600 GF |
600/750 |
660/825 |
KT83-GA |
647/711 |
KN-600 Nws |
600/750 |
4500x1600x2500 |
7800 |
|
KNC 800 GF |
800/1000 |
880/1100 |
KTA38-G5 |
880/970 |
KN-800 Nws |
800/1000 |
4500x1900x2500 |
9200 |
|
KNC 1000 GF |
1000/1250 |
1100/1562 |
KTA50-G3 |
1097/1227 |
KN-1000 Nws |
1000/1250 |
5000x2100x2600 |
10200 |
|
KNC 1200 GF |
1200/1500 |
1320/1650 |
KTA50-GS8 |
1287/1429 |
KN-1200 Nws |
1200/1500 |
5400x2200x2600 |
10600 |
|
KNC 1500 GF |
1500/1875 |
1650/2062 |
KTA50-G16A |
1650/1760 |
KN-1500 Nws |
1500/1875 |
5400x2200x2600 |
10600 |
Thov nco ntsoov:
1. Cov kev ntsuas saum toj no yog 50hz, ntsuas hluav taws xob 400/230V, fais fab tuag 0.8, 3-theem 4-xaim, 60Hz generators tuaj yeem kho raws li qhov tshwj xeeb xav tau ntawm cov neeg siv khoom.
2. Alternators tuaj yeem xaiv raws li qhov xav tau ntawm cov neeg siv khoom yog Keneng, Stanford, Leroy- Somer, Marathon thiab lwm lub npe nrov.
3. Cov kev qhia tshwj xeeb tuaj yeem hloov pauv yam tsis muaj ntawv ceeb toom.
Shipping Scenario ntawm 600KW Cummins Generator Teeb
FAQ
Q: Puas yog qhov kev vibration tsim thaum lub sijhawm ua haujlwm ntawm cov khoom siv cuam tshuam rau ib puag ncig?
A: Tus qauv hydraulic damping system txo kev co kis tau los ntawm ntau dua 60%. Thaum ntsia rau ntawm lub hauv paus pob zeb, qhov kev vibration amplitude tseem tsawg dua lossis sib npaug li 0.1 hli, ua tau raws li kev tiv thaiv kev tiv thaiv - kev co ntawm feem ntau cov tsev lag luam. Rau thaj chaw rhiab heev (piv txwv li, tsev kho mob, chaw sim), ib qho kev xaiv "tsawg- zaus damping" siv lub caij nplooj ntoos hlav-damper composite qauv tuaj yeem txwv kev vibration ntxiv rau hauv 0.05mm.
Q: Yuav tsum muaj kev saib xyuas tshwj xeeb li cas rau kev kaw lub sijhawm ntev (piv txwv li, dhau 6 lub hlis)?
A: Kev ncua sij hawm ncua sij hawm yuav tsum muaj peb -theem preservation raws tu qauv:
Roj System: Tshem cov tank thiab txhaj tshuaj tiv thaiv xeb
Lubrication System: Hloov cov roj tshwj xeeb khaws cia
Hluav taws xob System: Tshem cov roj teeb thiab ua txhua hli recharge
Peb muab cov ncauj lus qhia ntxaws txog kev khaws cia video lossis tuaj yeem xa cov kws tshaj lij kev pabcuam rau ntawm -kev txuag chaw (nqi ntxiv).
Q: Dab tsi tshwj xeeb qhov zoo ntawm cov qauv diesel no muab piv rau cov tshuab hluav taws xob roj sib npaug?
A: Ntawm qhov sib npaug ntawm cov khoom siv hluav taws xob, lub tshuab diesel nta:
30% sai pib-nce ( Tsawg dua lossis sib npaug li 8 vib nas this)
Qhov txias txias zoo tshaj - huab cua muaj peev xwm (pib ntawm -40℃vs. gas generators feem ntau Zoo dua lossis sib npaug rau -20 degree)
Tsis muaj kev vam khom rau cov kav dej, zoo tagnrho rau thaj chaw deb tsis muaj cov khoom siv hluav taws xob ntuj
Kev nyab xeeb thiab hloov tau yooj yim dua roj cia daws teeb meem
